Overview
In this IoT project, we will learn how to build an ESP32 Fingerprint Voting Machine with Live Web Dashboard using ESP32, R503 Fingerprint Sensor, 0.96” OLED Display, four candidate push buttons, and a professional web dashboard. The ESP32 Wi-Fi module connects the system to a local network and hosts a real-time voting dashboard directly from the device. The R503 fingerprint sensor is used to enroll voters and verify identity before voting, while the OLED display shows system status, scan instructions, voter name, candidate selection prompts, vote confirmation, and registration messages.
This ESP32-based biometric voting machine allows voters to register their fingerprint along with personal details such as name, ID number, date of birth, sex, and city. Once a registered voter scans their finger, the system opens a short voting window and the voter presses one of four candidate buttons to cast a vote. Each fingerprint can vote only once. The dashboard displays live vote distribution, turnout, leading candidate, live activity feed, vote history, registered voter records, and election results. Vote data can also be exported as a CSV file for record-keeping or analysis.
The live web dashboard makes this project more advanced by providing a user-friendly interface for voter enrollment, live election monitoring, vote history, voter management, election reset, and fingerprint deletion. This project is a practical and low-cost solution for building a secure electronic voting machine with real-time results and biometric voter verification.
Components Required
Following are the components required to make the ESP32 Fingerprint Voting Machine with Live Web Dashboard. All these components can be purchased from the given links.
| S.N. | Components Name | Quantity | Purchase Link |
|---|---|---|---|
| 1 | ESP32 Board | 1 | Amazon | AliExpress |
| 2 | R503 Fingerprint Sensor | 1 | Amazon | AliExpress |
| 3 | OLED Display 0.96" | 1 | Amazon | AliExpress |
| 4 | 10uF Electrolytic Capacitor | 2 | Amazon | AliExpress |
| 5 | 0.1uF Ceramic Capacitor | 4 | Amazon | AliExpress |
| 6 | Jumper Wires | 4 | Amazon | AliExpress |
Block Diagram of ESP32 Fingerprint Voting Machine
Let’s take a look at the block diagram of the ESP32-based Fingerprint Voting Machine with Live Web Dashboard.
In this system, the R503 fingerprint sensor works as the input device and sends fingerprint data to the ESP32 for voter verification. After a registered voter is verified, the ESP32 displays instructions on the OLED screen, waits for a candidate button press, records the vote, and updates the web dashboard for real-time election monitoring.
The dashboard can show registered voters, live vote counts, turnout, leading candidate, vote history, and other election details in a simple and organized way.
R503 Fingerprint Module
The R503 fingerprint sensor is a compact biometric fingerprint identification module used for fingerprint enrollment, storage, and matching. It uses an optical fingerprint sensing system to capture a finger image, extract fingerprint features, and compare them with stored templates inside the module.
The sensor supports both 1:1 matching and 1:N searching. During enrollment, the user places the same finger two times. The module processes both fingerprint images, generates a fingerprint template, and stores it in its internal memory. During verification, the module captures a new fingerprint image and compares it with stored templates to identify whether the fingerprint matches or not.
Features & Specifications
The R503 fingerprint sensor is suitable for security systems, attendance systems, access control, smart locks, and embedded biometric projects.
| Feature | Specification |
|---|---|
| Operating Voltage | DC 3.3V |
| Interface | UART, 3.3V TTL logic level |
| Default Baud Rate | 57600 bps |
| Baud Rate Range | 9600 to 115200 bps |
| Matching Mode | 1:1 and 1:N |
| Fingerprint Storage Capacity | 200 templates |
| Image Resolution | 508 dpi |
| Sensing Array | 192 × 192 pixels |
| Detection Area | 15 mm diameter |
| Fingerprint Image Capture Time | Less than 0.2 seconds |
| Feature Generation Time | Less than 500 ms |
| Template Size | 768 bytes |
| Characteristic Value Size | 384 bytes |
| Security Levels | 1 to 5, with 5 being the highest |
| False Acceptance Rate, FAR | Less than 0.001% |
| False Rejection Rate, FRR | Less than 1% |
| Working Current | Around 20 mA during fingerprint acquisition |
| Standby Current | Around 2 µA in touch standby mode |
| Working Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +75°C |
The module also includes functions for enrolling fingerprints, deleting templates, clearing the fingerprint library, searching stored fingerprints, reading template count, controlling the LED ring, and checking sensor status. It communicates using a serial UART protocol, making it easy to use with microcontrollers such as ESP32, Arduino, STM32, and Raspberry Pi Pico.
Wiring
The R503 fingerprint sensor uses a 6-pin MX1.0 connector. It communicates with the microcontroller through UART serial communication.
| R503 Pin | Pin Name | Description |
|---|---|---|
| 1 | Power Supply | DC 3.3V |
| 2 | GND | Ground |
| 3 | TXD | Data output from sensor |
| 4 | RXD | Data input to sensor |
| 5 | WAKEUP | Finger detection signal |
| 6 | 3.3VT | Touch induction power supply, DC 3–6V |
Circuit Diagram
Let’s take a look at the schematic of the ESP32-based Fingerprint Voting Machine.
In this circuit, the ESP32 works as the main controller and is connected with the R503 fingerprint sensor, OLED display, and four candidate push buttons on GPIO pins D5, D18, D19, and D23. The R503 fingerprint sensor communicates with the ESP32 through UART pins, while the OLED display uses the I2C pins for showing scan status, voter name, candidate selection prompts, vote confirmation, and system messages.
The four candidate push buttons are connected as active-low inputs with internal pull-up resistors. After a registered voter scans their fingerprint, they press one button to vote for Candidate 1, 2, 3, or 4. Voter enrollment is done only from the web dashboard, not from physical buttons. Pull-up resistors are used with the buttons, so the ESP32 can read a stable HIGH or LOW signal when a button is pressed. Capacitors are also added near the modules to make the power supply more stable and reduce noise in the circuit.
PCB Designing & Gerber Files
The schematic of the ESP32 Fingerprint Voting Machine was created in EasyEDA, and from there it was converted into a compact PCB layout.
The board is designed with mostly through-hole components to make easier assembly. You can view the 2D view of the PCB.
All of the critical components, including the ESP32 module, are placed on the front side of the PCB, which makes assembly easier and more reliable.
Here are the link of files that you can download for PCB manufacturing and PCB assembly services.
- Download: Schematic PDF
- Download: Gerber File
PCB Ordering Online & Assembly
The Gerber file for this ESP32 Fingerprint Voting Machine is provided above. You can download the Gerber file and place an order with a PCB manufacturer like AIVON for as low as $1 for a PCB Prototype.
To order the PCB, visit the AIVON Official Website and upload the Gerber file using the Quote Now option. You can then choose your required parameters, such as Material Type, Dimensions, Quantity, Thickness, and Solder Mask Color.
AIVON is making PCB prototyping and assembly more affordable for new users by offering $1 PCB Prototype and $35 PCB Assembly with Shipping fee $30 OFF on your first PCB order. With this promotion, you can enjoy free shipping on your first order and affordable assembly service for your project.
Here is the promotion link: AIVON PCB/PCBA Promotion Offer
Once all the details are filled in, select your country and shipping method. After confirming everything, you can place the order and wait for your boards to arrive.
Assembly of the ESP32 Fingerprint Voting Machine
After I ordered the custom PCB, I received it within just 3 days. The PCB quality was very good, and it looked clean and professional. It is a double-sided PCB, which makes the circuit compact and neat.
Then I started soldering and assembling all the components on the board. For the ESP32 board, OLED display, fingerprint sensor, and candidate buttons, I used female header pins where needed. This makes it easy to remove or replace the modules later if required.
I also soldered the required capacitors on different parts of the PCB. These capacitors help to keep the power supply stable and reduce noise in the circuit. For the R503 Fingerprint sensor, I used 6 jumper wires to connect it to the PCB board terminal.
After soldering all the parts, I connected all the modules and completed the final assembly of the IoT ESP32 Fingerprint Voting Machine device.
Source Code/program
Let us take a look at the programming part of this project.
The code starts by including the required libraries for Wi-Fi, web server, fingerprint sensor, OLED display, and ESP32 memory storage. The WiFi and WebServer libraries are used to connect the ESP32 to the local network and host the live voting dashboard. The Adafruit Fingerprint library is used to communicate with the R503 fingerprint sensor, while the Adafruit GFX library and Adafruit SSD1306 library are used to display messages on the OLED screen.
In the Wi-Fi section, the SSID and password are added so the ESP32 can connect to the network. After connecting, the ESP32 shows its IP address on the OLED display and Serial Monitor. This IP address can be opened in a browser to access the professional web dashboard.
The main loop checks for fingerprint scans, dashboard enrollment requests, and candidate button presses. When a registered voter scans their finger, the ESP32 verifies the fingerprint, checks whether that voter has already voted, opens a voting window, and records the selected candidate when a button is pressed. Vote counts and voter status are saved in ESP32 NVS memory and shown on the dashboard in real time. New voters can be registered from the dashboard by entering name, ID number, date of birth, sex, and city.
The code is divided into two main parts: the main FPS_Voting_Machine.ino file for ESP32 voting control and the dashboard.h file for the live web dashboard interface.
Main .ino code
Copy the following code and paste it to your Arduino IDE editor window.
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170 171 172 173 174 175 176 177 178 179 180 181 182 183 184 185 186 187 188 189 190 191 192 193 194 195 196 197 198 199 200 201 202 203 204 205 206 207 208 209 210 211 212 213 214 215 216 217 218 219 220 221 222 223 224 225 226 227 228 229 230 231 232 233 234 235 236 237 238 239 240 241 242 243 244 245 246 247 248 249 250 251 252 253 254 255 256 257 258 259 260 261 262 263 264 265 266 267 268 269 270 271 272 273 274 275 276 277 278 279 280 281 282 283 284 285 286 287 288 289 290 291 292 293 294 295 296 297 298 299 300 301 302 303 304 305 306 307 308 309 310 311 312 313 314 315 316 317 318 319 320 321 322 323 324 325 326 327 328 329 330 331 332 333 334 335 336 337 338 339 340 341 342 343 344 345 346 347 348 349 350 351 352 353 354 355 356 357 358 359 360 361 362 363 364 365 366 367 368 369 370 371 372 373 374 375 376 377 378 379 380 381 382 383 384 385 386 387 388 389 390 391 392 393 394 395 396 397 398 399 400 401 402 403 404 405 406 407 408 409 410 411 412 413 414 415 416 417 418 419 420 421 422 423 424 425 426 427 428 429 430 431 432 433 434 435 436 437 438 439 440 441 442 443 444 445 446 447 448 449 450 451 452 453 454 455 456 457 458 459 460 461 462 463 464 465 466 467 468 469 470 471 472 473 474 475 476 477 478 479 480 481 482 483 484 485 486 487 488 489 490 491 492 493 494 495 496 497 498 499 500 501 502 503 504 505 506 507 508 509 510 511 512 513 514 515 516 517 518 519 520 521 522 523 524 525 526 527 528 529 530 531 532 533 534 535 536 537 538 539 540 541 542 543 544 545 546 547 548 549 550 551 552 553 554 555 556 557 558 559 560 561 562 563 564 565 566 567 568 569 570 571 572 573 574 575 576 577 578 579 580 581 582 583 584 585 586 587 588 589 590 591 592 593 594 595 596 597 598 599 600 601 602 603 604 605 606 607 608 609 610 611 612 613 614 615 616 617 618 619 620 621 622 623 624 625 626 627 628 629 630 631 632 633 634 635 636 637 638 639 640 641 642 643 644 645 646 647 648 649 650 651 652 653 654 655 656 657 658 659 660 661 662 663 664 665 666 667 668 669 670 671 672 673 674 675 676 677 678 679 680 681 682 683 684 685 686 687 688 689 690 691 692 693 694 695 696 697 698 699 700 701 702 703 704 705 706 707 708 709 710 711 712 713 714 715 716 717 718 719 720 721 722 723 724 725 726 727 728 729 730 731 732 733 734 735 736 737 738 739 740 741 742 743 744 745 746 747 748 749 750 751 752 753 754 755 756 757 758 759 760 761 762 763 764 765 766 767 768 769 770 771 772 773 774 775 776 777 778 779 780 781 782 783 784 785 786 787 788 789 790 791 792 793 794 795 796 797 798 799 800 801 802 803 804 805 806 807 808 809 810 811 812 813 814 815 816 817 818 819 820 821 822 823 824 825 826 827 828 829 830 831 832 833 834 835 836 837 838 839 840 841 842 843 844 845 846 847 848 849 850 851 852 853 854 855 856 857 858 859 860 861 862 863 864 865 866 867 868 869 870 871 872 873 874 875 876 877 878 879 880 881 882 883 884 885 886 887 888 889 890 891 892 893 894 895 896 897 898 899 900 901 902 903 904 905 906 907 908 909 910 911 912 913 914 915 916 917 918 919 920 921 922 923 924 925 926 927 928 929 930 931 932 933 934 935 936 937 938 939 940 941 942 943 944 945 946 947 948 949 950 951 952 953 954 955 956 957 958 959 960 961 962 963 964 965 966 967 968 969 970 971 972 973 974 975 976 977 978 979 980 981 982 983 984 985 986 987 988 989 990 991 992 993 994 995 996 997 998 999 1000 1001 1002 1003 1004 1005 1006 1007 1008 1009 1010 1011 1012 1013 1014 1015 1016 1017 1018 1019 1020 1021 1022 1023 1024 1025 1026 1027 1028 1029 1030 1031 1032 1033 1034 1035 1036 1037 1038 1039 1040 1041 1042 1043 1044 1045 1046 1047 1048 1049 1050 1051 1052 1053 1054 1055 1056 1057 1058 1059 1060 1061 1062 1063 1064 1065 1066 1067 1068 1069 1070 1071 1072 1073 1074 1075 1076 1077 1078 1079 1080 1081 1082 1083 1084 1085 1086 1087 1088 1089 1090 1091 1092 1093 1094 1095 1096 1097 1098 1099 1100 1101 1102 1103 1104 1105 1106 1107 1108 1109 1110 1111 1112 1113 1114 1115 1116 1117 1118 1119 1120 1121 1122 1123 1124 1125 1126 1127 1128 1129 1130 1131 1132 1133 1134 1135 1136 1137 1138 1139 1140 1141 1142 1143 1144 1145 1146 1147 1148 1149 1150 1151 1152 1153 1154 1155 1156 1157 1158 1159 1160 1161 1162 1163 1164 1165 1166 1167 1168 1169 1170 1171 1172 1173 1174 1175 1176 1177 1178 1179 1180 1181 1182 1183 1184 1185 1186 1187 1188 1189 1190 1191 1192 1193 1194 1195 1196 1197 1198 1199 1200 1201 1202 1203 1204 1205 1206 1207 1208 1209 1210 1211 1212 1213 1214 1215 1216 1217 1218 1219 1220 1221 1222 1223 1224 1225 1226 1227 1228 1229 1230 1231 1232 1233 1234 1235 1236 1237 1238 1239 1240 1241 1242 1243 1244 1245 1246 1247 1248 1249 1250 1251 1252 1253 1254 1255 1256 1257 1258 1259 1260 1261 1262 1263 1264 1265 1266 1267 1268 1269 1270 1271 1272 1273 1274 1275 1276 1277 1278 1279 1280 1281 1282 1283 1284 1285 1286 1287 1288 1289 1290 1291 1292 1293 1294 1295 1296 1297 1298 1299 1300 1301 1302 1303 1304 1305 1306 1307 1308 1309 1310 1311 1312 1313 1314 1315 1316 1317 1318 1319 1320 1321 1322 1323 1324 1325 1326 1327 1328 1329 1330 1331 1332 1333 1334 1335 1336 1337 1338 1339 1340 1341 1342 1343 1344 1345 1346 1347 1348 1349 1350 1351 1352 1353 1354 1355 1356 1357 1358 1359 1360 1361 1362 1363 1364 1365 1366 1367 1368 1369 1370 1371 1372 1373 1374 1375 1376 1377 1378 1379 1380 1381 1382 1383 1384 1385 1386 1387 1388 1389 1390 1391 1392 1393 1394 1395 1396 1397 1398 1399 1400 1401 1402 1403 1404 1405 1406 1407 1408 1409 1410 1411 1412 1413 1414 1415 1416 1417 1418 1419 1420 1421 1422 1423 1424 1425 1426 1427 1428 1429 1430 1431 1432 1433 1434 1435 1436 1437 1438 1439 1440 1441 1442 1443 1444 1445 1446 1447 1448 1449 1450 1451 1452 1453 1454 1455 1456 1457 1458 1459 1460 1461 1462 1463 1464 1465 1466 1467 1468 1469 1470 1471 1472 1473 1474 1475 1476 1477 1478 1479 1480 1481 1482 1483 1484 1485 1486 1487 1488 1489 1490 1491 1492 1493 1494 1495 1496 1497 1498 1499 1500 1501 1502 1503 1504 1505 1506 1507 1508 1509 1510 1511 1512 1513 1514 1515 1516 1517 1518 1519 1520 1521 1522 1523 1524 1525 1526 1527 1528 1529 1530 1531 1532 1533 1534 1535 1536 1537 1538 1539 1540 1541 1542 1543 1544 1545 1546 1547 1548 1549 1550 1551 1552 1553 1554 1555 1556 1557 1558 1559 1560 1561 1562 1563 1564 1565 1566 1567 1568 1569 1570 1571 1572 1573 1574 1575 1576 1577 1578 1579 1580 1581 1582 1583 1584 1585 1586 1587 1588 1589 1590 1591 1592 1593 1594 1595 1596 1597 1598 1599 1600 1601 1602 1603 1604 1605 1606 1607 1608 1609 1610 1611 1612 1613 1614 1615 1616 1617 1618 1619 1620 1621 1622 1623 1624 1625 1626 1627 1628 1629 1630 1631 1632 1633 1634 1635 1636 1637 1638 1639 1640 1641 1642 1643 1644 1645 1646 1647 1648 1649 1650 1651 1652 1653 1654 1655 1656 1657 1658 1659 1660 1661 1662 1663 1664 1665 1666 1667 1668 1669 1670 1671 1672 1673 1674 1675 1676 1677 1678 1679 1680 1681 1682 1683 1684 1685 1686 1687 1688 1689 1690 1691 1692 1693 1694 1695 1696 1697 1698 1699 1700 1701 1702 1703 1704 1705 1706 1707 1708 1709 1710 1711 1712 1713 1714 1715 1716 1717 1718 1719 |
#include <Wire.h> #include <WiFi.h> #include <WebServer.h> #include <Preferences.h> #include <time.h> #include <Adafruit_GFX.h> #include <Adafruit_SSD1306.h> #include <Adafruit_Fingerprint.h> #include "dashboard.h" // ===================================================== // WIFI SETTINGS // ===================================================== const char* WIFI_SSID = "****************"; const char* WIFI_PASSWORD = "***************"; // Ontario / Toronto timezone const char* TIME_ZONE = "EST5EDT,M3.2.0/2,M11.1.0/2"; WebServer server(80); Preferences prefs; // ===================================================== // OLED SETTINGS // ===================================================== #define SCREEN_WIDTH 128 #define SCREEN_HEIGHT 64 #define OLED_RESET -1 #define OLED_ADDR 0x3C #define OLED_SDA 21 #define OLED_SCL 22 Adafruit_SSD1306 display(SCREEN_WIDTH, SCREEN_HEIGHT, &Wire, OLED_RESET); // ===================================================== // R503 FINGERPRINT SENSOR UART // ===================================================== #define FINGER_RX 16 #define FINGER_TX 17 HardwareSerial fingerSerial(2); Adafruit_Fingerprint finger = Adafruit_Fingerprint(&fingerSerial); // ===================================================== // CANDIDATE BUTTONS ONLY (active LOW, internal pull-up) // D5/D18/D19/D23 = Candidate 1-4 for voting after fingerprint scan. // Voter enrollment is dashboard-only (POST /api/enroll) — no enroll button. // ===================================================== #define BTN_CAND_1 5 #define BTN_CAND_2 18 #define BTN_CAND_3 19 #define BTN_CAND_4 23 #define NUM_CANDIDATES 4 #define VOTE_TIMEOUT_MS 15000 #define DEBOUNCE_MS 250 const uint8_t CAND_PINS[NUM_CANDIDATES] = {BTN_CAND_1, BTN_CAND_2, BTN_CAND_3, BTN_CAND_4}; const char* CANDIDATE_NAMES[NUM_CANDIDATES] = { "Candidate 1", "Candidate 2", "Candidate 3", "Candidate 4" }; unsigned long lastCandBtnTime[NUM_CANDIDATES] = {0, 0, 0, 0}; // ===================================================== // MATCH SETTINGS // ===================================================== #define MATCH_SECURITY_LEVEL 2 #define MAX_FINGERPRINTS 200 // ===================================================== // PROFILE STORAGE // ===================================================== struct PersonProfile { String name; String collegeId; String role; String department; String note; }; // ===================================================== // LOGGING // ===================================================== #define MAX_LOGS 80 struct AttendanceLog { String timeText; String event; int id; String name; String collegeId; String role; String department; String note; String candidate; String message; }; AttendanceLog logs[MAX_LOGS]; int logCount = 0; int logWriteIndex = 0; // ===================================================== // APP STATE // ===================================================== uint16_t nextEnrollID = 1; unsigned long lastIdleRefresh = 0; bool isEnrolling = false; bool cancelEnroll = false; bool duplicateFound = false; bool dashboardEnrollRequest = false; uint16_t cachedTemplateCount = 0; String cachedRegisteredJson = "{\"fingerprints\":[]}"; int candidateVotes[NUM_CANDIDATES] = {0, 0, 0, 0}; bool hasVoted[MAX_FINGERPRINTS + 1]; bool isSelectingCandidate = false; int pendingVoterId = -1; unsigned long voteWindowStart = 0; // Dashboard form values String pendingName = ""; String pendingCollegeId = ""; String pendingRole = ""; String pendingDepartment = ""; String pendingNote = ""; // ===================================================== // FUNCTION DECLARATIONS // ===================================================== void connectWiFi(); void setupTime(); void setupDashboardRoutes(); void smartDelay(unsigned long ms); String uptimeText(); String currentDateTimeText(); String jsonEscape(String s); String firstNameOnly(String fullName); void addLog(String event, int id, String message, String candidate = ""); AttendanceLog getLogByDisplayIndex(int i); void loadVoteState(); void saveVoteForVoter(uint16_t id); void saveCandidateVotes(); void clearVoterVoteState(uint16_t id); void resetAllVotes(); int getTotalVotes(); void castVote(int voterId, int candidateIndex); void handleCandidateSelection(); String profileKey(uint16_t id, const char* field); void saveProfile(uint16_t id, PersonProfile p); PersonProfile loadProfile(uint16_t id); void deleteProfile(uint16_t id); void oledScreen(String title, String line1 = "", String line2 = "", String line3 = ""); void oledBig(String title, String line1 = "", String line2 = ""); void oledScanScreen(); void oledScanAnimation(String title, String line1, uint16_t durationMs); void oledProgressBar(String title, String line1, uint8_t percent); void oledSuccessAnimation(String line1, String line2 = ""); void oledErrorAnimation(String line1, String line2 = ""); String clipText(String text, uint8_t maxChars); void drawCenteredText(String text, int y, uint8_t textSize); void drawTitleBar(String title); void drawMiniFingerprint(int x, int y); void drawLoadingDots(int x, int y, uint8_t frame); void drawMovingBar(int y, uint8_t frame); void drawProgress(uint8_t percent); void drawWiFiIcon(bool connected); bool buttonPressed(uint8_t pin, unsigned long &lastTime); int readCandidateButton(); bool checkCancelDuringEnroll(); void scanFingerprint(); uint8_t enrollFingerprint(uint16_t id); void waitForFingerRemove(); uint16_t findNextFreeID(uint16_t startID); void printSensorParameters(); void refreshTemplateCountSerialOnly(); void refreshTemplateCountCache(); void rebuildRegisteredCache(); void setMatchingSecuritySerialOnly(); // ===================================================== // SETUP // ===================================================== void setup() { Serial.begin(115200); delay(1000); for (int i = 0; i < NUM_CANDIDATES; i++) { pinMode(CAND_PINS[i], INPUT_PULLUP); } for (int i = 0; i <= MAX_FINGERPRINTS; i++) { hasVoted[i] = false; } prefs.begin("fps_db", false); loadVoteState(); Wire.begin(OLED_SDA, OLED_SCL); if (!display.begin(SSD1306_SWITCHCAPVCC, OLED_ADDR)) { Serial.println("OLED not found"); while (1) { delay(1000); } } display.clearDisplay(); display.setTextWrap(false); display.display(); oledBig("STARTING", "Fingerprint", "Voting System"); smartDelay(900); connectWiFi(); setupTime(); setupDashboardRoutes(); fingerSerial.begin(57600, SERIAL_8N1, FINGER_RX, FINGER_TX); finger.begin(57600); smartDelay(500); oledScanAnimation("CHECKING", "Sensor", 900); if (finger.verifyPassword()) { Serial.println("Fingerprint sensor found!"); addLog("INFO", -1, "Fingerprint sensor ready"); oledSuccessAnimation("Sensor ready"); smartDelay(900); } else { Serial.println("Fingerprint sensor not found!"); addLog("ERROR", -1, "Fingerprint sensor not found"); oledErrorAnimation("Sensor not found", "Check wiring"); while (1) { server.handleClient(); delay(10); } } printSensorParameters(); setMatchingSecuritySerialOnly(); refreshTemplateCountSerialOnly(); rebuildRegisteredCache(); nextEnrollID = findNextFreeID(1); Serial.print("Next enroll ID: "); Serial.println(nextEnrollID); addLog("INFO", -1, "System ready"); smartDelay(500); oledScanScreen(); } // ===================================================== // LOOP // ===================================================== void loop() { server.handleClient(); // Enrollment starts ONLY from the web dashboard (never from physical buttons). if (dashboardEnrollRequest && !isEnrolling && !isSelectingCandidate) { dashboardEnrollRequest = false; if (pendingName.length() > 0) { addLog("ENROLL", -1, "Enrollment started for " + pendingName); } else { addLog("ENROLL", -1, "Enrollment started"); } isEnrolling = true; cancelEnroll = false; duplicateFound = false; uint8_t result = enrollFingerprint(nextEnrollID); if (cancelEnroll) { addLog("CANCEL", -1, "Enrollment cancelled"); oledBig("CANCELLED", "Back to scan"); smartDelay(1200); } else if (duplicateFound) { addLog("DUPLICATE", finger.fingerID, "Fingerprint already exists"); smartDelay(1200); } else if (result == FINGERPRINT_OK) { PersonProfile p; p.name = pendingName; p.collegeId = pendingCollegeId; p.role = pendingRole; p.department = pendingDepartment; p.note = pendingNote; saveProfile(nextEnrollID, p); String savedName = firstNameOnly(p.name); if (savedName.length() == 0) { savedName = "ID " + String(nextEnrollID); } String enrollMsg = "Fingerprint enrolled successfully"; if (p.name.length() > 0) { enrollMsg = p.name + " enrolled successfully"; } addLog("ENROLLED", nextEnrollID, enrollMsg); oledSuccessAnimation("Saved", savedName); Serial.print("Enrollment successful. ID: "); Serial.println(nextEnrollID); smartDelay(1200); refreshTemplateCountSerialOnly(); rebuildRegisteredCache(); nextEnrollID = findNextFreeID(nextEnrollID + 1); } else { addLog("ERROR", -1, "Enrollment failed"); oledErrorAnimation("Not saved", "Try again"); smartDelay(1600); } pendingName = ""; pendingCollegeId = ""; pendingRole = ""; pendingDepartment = ""; pendingNote = ""; isEnrolling = false; cancelEnroll = false; duplicateFound = false; oledScanScreen(); } if (isSelectingCandidate) { handleCandidateSelection(); } if (!isEnrolling && !isSelectingCandidate) { scanFingerprint(); } delay(30); } // ===================================================== // SMART DELAY // ===================================================== void smartDelay(unsigned long ms) { unsigned long start = millis(); while (millis() - start < ms) { server.handleClient(); delay(5); } } // ===================================================== // WIFI + TIME + DASHBOARD ROUTES // ===================================================== void connectWiFi() { WiFi.mode(WIFI_STA); WiFi.begin(WIFI_SSID, WIFI_PASSWORD); unsigned long start = millis(); uint8_t frame = 0; while (WiFi.status() != WL_CONNECTED && millis() - start < 15000) { display.clearDisplay(); drawTitleBar("WIFI"); drawCenteredText("Connecting", 24, 1); drawLoadingDots(28, 42, frame); display.display(); frame++; delay(300); } if (WiFi.status() == WL_CONNECTED) { Serial.print("WiFi connected. IP: "); Serial.println(WiFi.localIP()); oledBig("WIFI OK", "IP Address", WiFi.localIP().toString()); smartDelay(5000); } else { Serial.println("WiFi not connected."); oledBig("WIFI OFF", "Dashboard offline"); smartDelay(1800); } } void setupTime() { if (WiFi.status() != WL_CONNECTED) { Serial.println("WiFi not connected. NTP skipped."); return; } configTzTime(TIME_ZONE, "pool.ntp.org", "time.nist.gov", "time.google.com"); Serial.print("Syncing time"); struct tm timeinfo; int retry = 0; while (!getLocalTime(&timeinfo, 1000) && retry < 12) { Serial.print("."); retry++; server.handleClient(); } Serial.println(); if (retry < 12) { Serial.print("Time synced: "); Serial.println(currentDateTimeText()); } else { Serial.println("Time sync failed. Using uptime fallback."); } } void setupDashboardRoutes() { server.on("/", HTTP_GET, []() { server.send_P(200, "text/html", DASHBOARD_HTML); }); server.on("/api/status", HTTP_GET, []() { String lastJson = "null"; if (logCount > 0) { AttendanceLog l = getLogByDisplayIndex(logCount - 1); lastJson = "{"; lastJson += "\"time\":\"" + jsonEscape(l.timeText) + "\","; lastJson += "\"event\":\"" + jsonEscape(l.event) + "\","; lastJson += "\"id\":" + String(l.id) + ","; lastJson += "\"name\":\"" + jsonEscape(l.name) + "\","; lastJson += "\"collegeId\":\"" + jsonEscape(l.collegeId) + "\","; lastJson += "\"role\":\"" + jsonEscape(l.role) + "\","; lastJson += "\"department\":\"" + jsonEscape(l.department) + "\","; lastJson += "\"note\":\"" + jsonEscape(l.note) + "\","; lastJson += "\"candidate\":\"" + jsonEscape(l.candidate) + "\","; lastJson += "\"message\":\"" + jsonEscape(l.message) + "\""; lastJson += "}"; } String voteCountsJson = "["; for (int i = 0; i < NUM_CANDIDATES; i++) { if (i > 0) { voteCountsJson += ","; } voteCountsJson += String(candidateVotes[i]); } voteCountsJson += "]"; String candidatesJson = "["; for (int i = 0; i < NUM_CANDIDATES; i++) { if (i > 0) { candidatesJson += ","; } candidatesJson += "\"" + jsonEscape(String(CANDIDATE_NAMES[i])) + "\""; } candidatesJson += "]"; String json = "{"; json += "\"wifi\":" + String(WiFi.status() == WL_CONNECTED ? "true" : "false") + ","; json += "\"ip\":\"" + String(WiFi.status() == WL_CONNECTED ? WiFi.localIP().toString() : "") + "\","; json += "\"templates\":" + String(cachedTemplateCount) + ","; json += "\"nextId\":" + String(nextEnrollID) + ","; json += "\"logCount\":" + String(logCount) + ","; json += "\"voteCounts\":" + voteCountsJson + ","; json += "\"totalVotes\":" + String(getTotalVotes()) + ","; json += "\"totalVoters\":" + String(cachedTemplateCount) + ","; json += "\"candidates\":" + candidatesJson + ","; json += "\"isEnrolling\":" + String(isEnrolling ? "true" : "false") + ","; json += "\"isSelectingVote\":" + String(isSelectingCandidate ? "true" : "false") + ","; json += "\"pendingVoterId\":" + String(pendingVoterId) + ","; json += "\"sensor\":\"Ready\","; json += "\"last\":" + lastJson; json += "}"; server.send(200, "application/json", json); }); server.on("/api/logs", HTTP_GET, []() { String json = "{\"logs\":["; for (int i = 0; i < logCount; i++) { AttendanceLog l = getLogByDisplayIndex(i); if (i > 0) { json += ","; } json += "{"; json += "\"time\":\"" + jsonEscape(l.timeText) + "\","; json += "\"event\":\"" + jsonEscape(l.event) + "\","; json += "\"id\":" + String(l.id) + ","; json += "\"name\":\"" + jsonEscape(l.name) + "\","; json += "\"collegeId\":\"" + jsonEscape(l.collegeId) + "\","; json += "\"role\":\"" + jsonEscape(l.role) + "\","; json += "\"department\":\"" + jsonEscape(l.department) + "\","; json += "\"note\":\"" + jsonEscape(l.note) + "\","; json += "\"candidate\":\"" + jsonEscape(l.candidate) + "\","; json += "\"message\":\"" + jsonEscape(l.message) + "\""; json += "}"; } json += "]}"; server.send(200, "application/json", json); }); server.on("/api/registered", HTTP_GET, []() { server.send(200, "application/json", cachedRegisteredJson); }); server.on("/api/enroll", HTTP_POST, []() { if (isEnrolling || dashboardEnrollRequest) { server.send(409, "application/json", "{\"ok\":false,\"message\":\"Enrollment already running\"}"); return; } pendingName = server.arg("name"); pendingCollegeId = server.arg("collegeId"); pendingRole = server.arg("role"); pendingDepartment = server.arg("department"); pendingNote = server.arg("note"); dashboardEnrollRequest = true; String msg = "Enroll requested from dashboard"; if (pendingName.length() > 0) { msg += " for " + pendingName; } addLog("ENROLL REQUEST", -1, msg); server.send(200, "application/json", "{\"ok\":true,\"message\":\"Enrollment requested\"}"); }); server.on("/api/cancel", HTTP_POST, []() { cancelEnroll = true; dashboardEnrollRequest = false; addLog("CANCEL", -1, "Cancel requested from dashboard"); server.send(200, "application/json", "{\"ok\":true,\"message\":\"Cancel requested\"}"); }); server.on("/api/fingerprint", HTTP_DELETE, []() { if (!server.hasArg("id")) { server.send(400, "application/json", "{\"ok\":false,\"message\":\"Missing ID\"}"); return; } int id = server.arg("id").toInt(); if (id < 1 || id > MAX_FINGERPRINTS) { server.send(400, "application/json", "{\"ok\":false,\"message\":\"Invalid ID\"}"); return; } if (isEnrolling) { server.send(409, "application/json", "{\"ok\":false,\"message\":\"Enrollment running. Try again later.\"}"); return; } uint8_t p = finger.deleteModel(id); smartDelay(150); uint8_t verify = finger.loadModel(id); if (p == FINGERPRINT_OK && verify != FINGERPRINT_OK) { deleteProfile(id); clearVoterVoteState(id); addLog("DELETE", id, "Fingerprint deleted from sensor memory"); refreshTemplateCountSerialOnly(); rebuildRegisteredCache(); nextEnrollID = findNextFreeID(1); server.send(200, "application/json", "{\"ok\":true,\"message\":\"Fingerprint deleted from sensor memory\"}"); } else if (p == FINGERPRINT_OK && verify == FINGERPRINT_OK) { addLog("ERROR", id, "Delete command sent but fingerprint still exists"); server.send(500, "application/json", "{\"ok\":false,\"message\":\"Delete command sent but fingerprint still exists in sensor\"}"); } else { addLog("ERROR", id, "Delete failed"); server.send(500, "application/json", "{\"ok\":false,\"message\":\"Delete failed. Fingerprint may not exist or sensor rejected command\"}"); } }); server.on("/api/export", HTTP_GET, []() { String csv = "time,event,fingerprint_id,name,college_id,role,department,candidate,message "; for (int i = 0; i < logCount; i++) { AttendanceLog l = getLogByDisplayIndex(i); csv += "\"" + l.timeText + "\","; csv += "\"" + l.event + "\","; csv += String(l.id) + ","; csv += "\"" + l.name + "\","; csv += "\"" + l.collegeId + "\","; csv += "\"" + l.role + "\","; csv += "\"" + l.department + "\","; csv += "\"" + l.candidate + "\","; csv += "\"" + l.message + "\" "; } server.sendHeader("Content-Disposition", "attachment; filename=vote_logs.csv"); server.send(200, "text/csv", csv); }); server.on("/api/reset-votes", HTTP_POST, []() { if (isEnrolling || isSelectingCandidate) { server.send(409, "application/json", "{\"ok\":false,\"message\":\"Cannot reset while enrollment or voting is active\"}"); return; } resetAllVotes(); server.send(200, "application/json", "{\"ok\":true,\"message\":\"Election reset successfully\"}"); }); server.begin(); Serial.println("Dashboard server started."); } // ===================================================== // PROFILE STORAGE FUNCTIONS // ===================================================== String profileKey(uint16_t id, const char* field) { return String(id) + "_" + String(field); } void saveProfile(uint16_t id, PersonProfile p) { prefs.putString(profileKey(id, "name").c_str(), p.name); prefs.putString(profileKey(id, "cid").c_str(), p.collegeId); prefs.putString(profileKey(id, "role").c_str(), p.role); prefs.putString(profileKey(id, "dept").c_str(), p.department); prefs.putString(profileKey(id, "note").c_str(), p.note); } PersonProfile loadProfile(uint16_t id) { PersonProfile p; p.name = prefs.getString(profileKey(id, "name").c_str(), ""); p.collegeId = prefs.getString(profileKey(id, "cid").c_str(), ""); p.role = prefs.getString(profileKey(id, "role").c_str(), ""); p.department = prefs.getString(profileKey(id, "dept").c_str(), ""); p.note = prefs.getString(profileKey(id, "note").c_str(), ""); return p; } void deleteProfile(uint16_t id) { prefs.remove(profileKey(id, "name").c_str()); prefs.remove(profileKey(id, "cid").c_str()); prefs.remove(profileKey(id, "role").c_str()); prefs.remove(profileKey(id, "dept").c_str()); prefs.remove(profileKey(id, "note").c_str()); prefs.remove(profileKey(id, "voted").c_str()); } // ===================================================== // LOG + TIME FUNCTIONS // ===================================================== String uptimeText() { return currentDateTimeText(); } String currentDateTimeText() { struct tm timeinfo; if (getLocalTime(&timeinfo, 1000)) { char buf[24]; strftime(buf, sizeof(buf), "%Y-%m-%d %H:%M:%S", &timeinfo); return String(buf); } unsigned long total = millis() / 1000; unsigned long h = total / 3600; unsigned long m = (total % 3600) / 60; unsigned long s = total % 60; char buf[24]; snprintf(buf, sizeof(buf), "UPTIME %02lu:%02lu:%02lu", h, m, s); return String(buf); } String jsonEscape(String s) { s.replace("\", "\\"); s.replace("\"", "\\""); s.replace(" ", "\n"); s.replace(" ", ""); return s; } String firstNameOnly(String fullName) { fullName.trim(); if (fullName.length() == 0) { return ""; } int spaceIndex = fullName.indexOf(' '); if (spaceIndex > 0) { return fullName.substring(0, spaceIndex); } return fullName; } void addLog(String event, int id, String message, String candidate) { logs[logWriteIndex].timeText = uptimeText(); logs[logWriteIndex].event = event; logs[logWriteIndex].id = id; logs[logWriteIndex].message = message; logs[logWriteIndex].candidate = candidate; logs[logWriteIndex].name = ""; logs[logWriteIndex].collegeId = ""; logs[logWriteIndex].role = ""; logs[logWriteIndex].department = ""; logs[logWriteIndex].note = ""; if (id >= 1 && id <= MAX_FINGERPRINTS) { PersonProfile p = loadProfile(id); logs[logWriteIndex].name = p.name; logs[logWriteIndex].collegeId = p.collegeId; logs[logWriteIndex].role = p.role; logs[logWriteIndex].department = p.department; logs[logWriteIndex].note = p.note; } logWriteIndex = (logWriteIndex + 1) % MAX_LOGS; if (logCount < MAX_LOGS) { logCount++; } Serial.print("[LOG] "); Serial.print(event); Serial.print(" ID="); Serial.print(id); Serial.print(" "); Serial.println(message); } AttendanceLog getLogByDisplayIndex(int i) { int start = (logWriteIndex - logCount + MAX_LOGS) % MAX_LOGS; int idx = (start + i) % MAX_LOGS; return logs[idx]; } // ===================================================== // OLED DISPLAY FUNCTIONS // ===================================================== String clipText(String text, uint8_t maxChars) { text.trim(); if (text.length() <= maxChars) { return text; } if (maxChars <= 1) { return text.substring(0, maxChars); } return text.substring(0, maxChars - 1) + "."; } void drawCenteredText(String text, int y, uint8_t textSize) { text.trim(); uint8_t maxChars = (textSize == 2) ? 10 : 21; text = clipText(text, maxChars); int charWidth = 6 * textSize; int textWidth = text.length() * charWidth; int x = (SCREEN_WIDTH - textWidth) / 2; if (x < 0) { x = 0; } display.setTextSize(textSize); display.setTextColor(SSD1306_WHITE, SSD1306_BLACK); display.setCursor(x, y); display.print(text); } void drawWiFiIcon(bool connected) { int x = 113; int y = 2; if (connected) { display.drawCircle(x + 7, y + 11, 1, SSD1306_WHITE); display.drawLine(x + 2, y + 8, x + 7, y + 4, SSD1306_WHITE); display.drawLine(x + 7, y + 4, x + 12, y + 8, SSD1306_WHITE); display.drawLine(x + 4, y + 10, x + 7, y + 8, SSD1306_WHITE); display.drawLine(x + 7, y + 8, x + 10, y + 10, SSD1306_WHITE); } else { display.drawRect(x + 1, y + 3, 12, 9, SSD1306_WHITE); display.drawLine(x, y + 2, x + 14, y + 13, SSD1306_WHITE); display.drawLine(x + 14, y + 2, x, y + 13, SSD1306_WHITE); } } void drawTitleBar(String title) { display.fillRect(0, 0, 128, 16, SSD1306_BLACK); String shortTitle = clipText(title, 16); int textWidth = shortTitle.length() * 6; int x = (112 - textWidth) / 2; if (x < 0) { x = 0; } display.setTextSize(1); display.setTextColor(SSD1306_WHITE, SSD1306_BLACK); display.setCursor(x, 2); display.print(shortTitle); drawWiFiIcon(WiFi.status() == WL_CONNECTED); display.drawLine(0, 15, 127, 15, SSD1306_WHITE); } void oledScreen(String title, String line1, String line2, String line3) { display.clearDisplay(); display.setTextWrap(false); drawTitleBar(title); if (line1.length() > 0) { drawCenteredText(line1, 22, 1); } if (line2.length() > 0) { drawCenteredText(line2, 36, 1); } if (line3.length() > 0) { drawCenteredText(line3, 50, 1); } display.display(); } void oledBig(String title, String line1, String line2) { display.clearDisplay(); display.setTextWrap(false); drawTitleBar(title); if (line1.length() > 0) { drawCenteredText(line1, 24, 1); } if (line2.length() > 0) { drawCenteredText(line2, 42, 1); } display.display(); } void drawMiniFingerprint(int x, int y) { display.drawCircle(x + 18, y + 18, 17, SSD1306_WHITE); display.drawCircle(x + 18, y + 18, 12, SSD1306_WHITE); display.drawCircle(x + 18, y + 18, 7, SSD1306_WHITE); display.fillRect(x - 2, y + 28, 42, 14, SSD1306_BLACK); display.fillRect(x - 2, y - 2, 7, 44, SSD1306_BLACK); display.fillRect(x + 32, y - 2, 8, 44, SSD1306_BLACK); display.drawLine(x + 18, y + 18, x + 18, y + 36, SSD1306_WHITE); display.drawLine(x + 12, y + 21, x + 10, y + 35, SSD1306_WHITE); display.drawLine(x + 24, y + 21, x + 28, y + 34, SSD1306_WHITE); } void drawLoadingDots(int x, int y, uint8_t frame) { display.setTextSize(1); display.setTextColor(SSD1306_WHITE, SSD1306_BLACK); display.setCursor(x, y); display.print("Please wait"); for (uint8_t i = 0; i < frame % 4; i++) { display.print("."); } } void drawMovingBar(int y, uint8_t frame) { int boxX = 12; int boxW = 104; int fillW = 22; int pos = (frame * 8) % (boxW - fillW); display.drawRect(boxX, y, boxW, 8, SSD1306_WHITE); display.fillRect(boxX + 2 + pos, y + 2, fillW, 4, SSD1306_WHITE); } void drawProgress(uint8_t percent) { if (percent > 100) { percent = 100; } int barX = 10; int barY = 52; int barW = 108; int barH = 9; display.drawRect(barX, barY, barW, barH, SSD1306_WHITE); int fillW = map(percent, 0, 100, 0, barW - 4); display.fillRect(barX + 2, barY + 2, fillW, barH - 4, SSD1306_WHITE); display.setTextSize(1); display.setTextColor(SSD1306_WHITE, SSD1306_BLACK); display.setCursor(52, 41); display.print(percent); display.print("%"); } void oledScanScreen() { static uint8_t idleFrame = 0; idleFrame++; display.clearDisplay(); display.setTextWrap(false); drawTitleBar("SCAN TO VOTE"); drawMiniFingerprint(8, 22); display.setTextSize(1); display.setTextColor(SSD1306_WHITE, SSD1306_BLACK); display.setCursor(56, 24); display.print("Scan to vote"); display.setCursor(56, 38); display.print("Waiting"); for (uint8_t i = 0; i < idleFrame % 4; i++) { display.print("."); } int r = 3 + (idleFrame % 4); display.drawCircle(103, 50, r, SSD1306_WHITE); display.display(); } void oledScanAnimation(String title, String line1, uint16_t durationMs) { unsigned long startTime = millis(); uint8_t frame = 0; while (millis() - startTime < durationMs) { server.handleClient(); display.clearDisplay(); display.setTextWrap(false); drawTitleBar(title); drawMiniFingerprint(8, 21); display.setTextSize(1); display.setTextColor(SSD1306_WHITE, SSD1306_BLACK); display.setCursor(56, 24); display.print(clipText(line1, 11)); drawLoadingDots(56, 38, frame); int scanY = 22 + ((frame * 4) % 32); display.drawLine(8, scanY, 45, scanY, SSD1306_WHITE); display.drawLine(8, scanY + 1, 45, scanY + 1, SSD1306_WHITE); drawMovingBar(54, frame); display.display(); frame++; delay(100); } } void oledProgressBar(String title, String line1, uint8_t percent) { display.clearDisplay(); display.setTextWrap(false); drawTitleBar(title); drawCenteredText(line1, 24, 1); drawProgress(percent); display.display(); } void oledSuccessAnimation(String line1, String line2) { for (int r = 3; r <= 14; r += 3) { server.handleClient(); display.clearDisplay(); display.setTextWrap(false); drawTitleBar("SUCCESS"); display.drawCircle(64, 34, r, SSD1306_WHITE); if (r >= 9) { display.drawLine(56, 34, 62, 41, SSD1306_WHITE); display.drawLine(62, 41, 74, 27, SSD1306_WHITE); display.drawLine(56, 35, 62, 42, SSD1306_WHITE); display.drawLine(62, 42, 74, 28, SSD1306_WHITE); } display.display(); smartDelay(120); } smartDelay(300); if (line2.length() > 0) { oledBig("SUCCESS", line1, line2); } else { oledBig("SUCCESS", line1); } } void oledErrorAnimation(String line1, String line2) { for (int i = 0; i < 3; i++) { server.handleClient(); display.clearDisplay(); display.setTextWrap(false); drawTitleBar("NOTICE"); display.drawCircle(64, 34, 13, SSD1306_WHITE); display.drawLine(56, 26, 72, 42, SSD1306_WHITE); display.drawLine(72, 26, 56, 42, SSD1306_WHITE); display.drawLine(57, 26, 73, 42, SSD1306_WHITE); display.drawLine(73, 26, 57, 42, SSD1306_WHITE); display.display(); smartDelay(180); display.clearDisplay(); drawTitleBar("NOTICE"); display.display(); smartDelay(100); } if (line2.length() > 0) { oledBig("TRY AGAIN", line1, line2); } else { oledBig("TRY AGAIN", line1); } } // ===================================================== // BUTTON HANDLING // ===================================================== bool buttonPressed(uint8_t pin, unsigned long &lastTime) { if (digitalRead(pin) == LOW) { if (millis() - lastTime > DEBOUNCE_MS) { lastTime = millis(); return true; } } return false; } int readCandidateButton() { // Candidate buttons are ignored outside the post-scan voting window. if (!isSelectingCandidate || isEnrolling) { return -1; } for (int i = 0; i < NUM_CANDIDATES; i++) { if (buttonPressed(CAND_PINS[i], lastCandBtnTime[i])) { while (digitalRead(CAND_PINS[i]) == LOW) { server.handleClient(); delay(10); } return i; } } return -1; } bool checkCancelDuringEnroll() { server.handleClient(); if (cancelEnroll) { cancelEnroll = true; oledBig("CANCELLED", "Back to scan"); smartDelay(800); return true; } return false; } // ===================================================== // SCAN FINGERPRINT - STABLE VERSION // ===================================================== void scanFingerprint() { uint8_t p = finger.getImage(); if (p == FINGERPRINT_NOFINGER) { if (millis() - lastIdleRefresh > 700) { lastIdleRefresh = millis(); oledScanScreen(); } return; } if (p != FINGERPRINT_OK) { addLog("ERROR", -1, "Could not read fingerprint"); oledErrorAnimation("Could not read", "Place properly"); smartDelay(800); waitForFingerRemove(); oledScanScreen(); return; } oledScreen("SCANNING", "Hold finger", "Reading..."); p = finger.image2Tz(1); if (p != FINGERPRINT_OK) { addLog("ERROR", -1, "Fingerprint image not clear"); oledErrorAnimation("Finger not clear", "Try again"); smartDelay(800); waitForFingerRemove(); oledScanScreen(); return; } refreshTemplateCountSerialOnly(); if (finger.templateCount == 0) { addLog("NOT FOUND", -1, "No fingerprints stored"); oledBig("NOT FOUND", "No saved print"); smartDelay(1600); waitForFingerRemove(); oledScanScreen(); return; } oledScreen("SEARCHING", "Please wait", "Checking..."); // IMPORTANT: // fingerSearch(1) is more reliable for your R503. // If it fails, fastSearch is tried as fallback. p = finger.fingerSearch(1); if (p != FINGERPRINT_OK) { p = finger.fingerFastSearch(); } if (p == FINGERPRINT_OK) { int id = finger.fingerID; PersonProfile profile = loadProfile(id); String fullName = profile.name; String displayName = firstNameOnly(fullName); if (displayName.length() == 0) { displayName = "ID " + String(id); } String logName = fullName; if (logName.length() == 0) { logName = "ID " + String(id); } waitForFingerRemove(); if (id >= 1 && id <= MAX_FINGERPRINTS && hasVoted[id]) { addLog("ALREADY VOTED", id, logName + " already voted"); oledErrorAnimation("Already Voted", displayName); smartDelay(1500); oledScanScreen(); return; } if (id >= 1 && id <= MAX_FINGERPRINTS) { pendingVoterId = id; isSelectingCandidate = true; voteWindowStart = millis(); addLog("VOTE PENDING", id, logName + " select candidate"); oledScreen("VOTING", "Welcome " + clipText(displayName, 14), "Press Candidate Btn"); return; } addLog("MATCH", id, logName + " matched"); oledSuccessAnimation("Matched", displayName); smartDelay(1500); oledScanScreen(); return; } if (p == FINGERPRINT_NOTFOUND) { addLog("NOT FOUND", -1, "No matching fingerprint"); oledErrorAnimation("Not found", "No match"); smartDelay(1200); waitForFingerRemove(); oledScanScreen(); return; } addLog("ERROR", -1, "Fingerprint search failed"); oledErrorAnimation("Search failed", "Try again"); smartDelay(1200); waitForFingerRemove(); oledScanScreen(); } // ===================================================== // ENROLL FINGERPRINT // ===================================================== uint8_t enrollFingerprint(uint16_t id) { int p = -1; oledProgressBar("ENROLLING", "Place finger", 10); while (p != FINGERPRINT_OK) { server.handleClient(); if (checkCancelDuringEnroll()) { return 255; } p = finger.getImage(); if (p == FINGERPRINT_OK) { oledProgressBar("ENROLLING", "Checking", 20); smartDelay(500); break; } else if (p == FINGERPRINT_NOFINGER) { // waiting } else { oledErrorAnimation("Could not read", "Try again"); return p; } delay(100); } if (checkCancelDuringEnroll()) { return 255; } p = finger.image2Tz(1); if (p != FINGERPRINT_OK) { oledErrorAnimation("Finger not clear", "Try again"); return p; } refreshTemplateCountSerialOnly(); if (finger.templateCount > 0) { oledProgressBar("CHECKING", "Existing", 30); uint8_t searchResult = finger.fingerSearch(1); if (searchResult != FINGERPRINT_OK) { searchResult = finger.fingerFastSearch(); } if (searchResult == FINGERPRINT_OK) { duplicateFound = true; PersonProfile existingProfile = loadProfile(finger.fingerID); String existingName = firstNameOnly(existingProfile.name); if (existingName.length() == 0) { existingName = "ID " + String(finger.fingerID); } addLog("DUPLICATE", finger.fingerID, "Already enrolled"); oledBig("ALREADY", existingName); smartDelay(2500); waitForFingerRemove(); return 255; } } oledProgressBar("ENROLLING", "First scan OK", 40); smartDelay(600); oledProgressBar("ENROLLING", "Remove finger", 50); smartDelay(1200); while (finger.getImage() != FINGERPRINT_NOFINGER) { server.handleClient(); if (checkCancelDuringEnroll()) { return 255; } delay(100); } smartDelay(500); p = -1; oledProgressBar("ENROLLING", "Same finger", 65); while (p != FINGERPRINT_OK) { server.handleClient(); if (checkCancelDuringEnroll()) { return 255; } p = finger.getImage(); if (p == FINGERPRINT_OK) { oledProgressBar("ENROLLING", "Second OK", 75); smartDelay(500); break; } else if (p == FINGERPRINT_NOFINGER) { // waiting } else { oledErrorAnimation("Could not read", "Try again"); return p; } delay(100); } if (checkCancelDuringEnroll()) { return 255; } p = finger.image2Tz(2); if (p != FINGERPRINT_OK) { oledErrorAnimation("Finger not clear", "Try again"); return p; } oledProgressBar("PROCESSING", "Creating", 85); p = finger.createModel(); if (p == FINGERPRINT_OK) { // model created } else if (p == FINGERPRINT_ENROLLMISMATCH) { oledErrorAnimation("Mismatch", "Use same finger"); return p; } else { oledErrorAnimation("Could not save", "Try again"); return p; } oledProgressBar("SAVING", "Please wait", 95); p = finger.storeModel(id); if (p == FINGERPRINT_OK) { oledProgressBar("SAVING", "Complete", 100); smartDelay(500); return FINGERPRINT_OK; } else { oledErrorAnimation("Memory problem", "Not saved"); return p; } } // ===================================================== // VOTING FUNCTIONS // ===================================================== void loadVoteState() { for (int i = 1; i <= MAX_FINGERPRINTS; i++) { hasVoted[i] = prefs.getBool(profileKey(i, "voted").c_str(), false); } candidateVotes[0] = prefs.getUInt("votes_c1", 0); candidateVotes[1] = prefs.getUInt("votes_c2", 0); candidateVotes[2] = prefs.getUInt("votes_c3", 0); candidateVotes[3] = prefs.getUInt("votes_c4", 0); } void saveVoteForVoter(uint16_t id) { prefs.putBool(profileKey(id, "voted").c_str(), true); } void saveCandidateVotes() { prefs.putUInt("votes_c1", candidateVotes[0]); prefs.putUInt("votes_c2", candidateVotes[1]); prefs.putUInt("votes_c3", candidateVotes[2]); prefs.putUInt("votes_c4", candidateVotes[3]); } void clearVoterVoteState(uint16_t id) { if (id >= 1 && id <= MAX_FINGERPRINTS) { hasVoted[id] = false; } prefs.remove(profileKey(id, "voted").c_str()); } void resetAllVotes() { for (int i = 1; i <= MAX_FINGERPRINTS; i++) { clearVoterVoteState(i); } for (int i = 0; i < NUM_CANDIDATES; i++) { candidateVotes[i] = 0; } saveCandidateVotes(); addLog("RESET", -1, "Election reset - all votes cleared"); } int getTotalVotes() { int total = 0; for (int i = 0; i < NUM_CANDIDATES; i++) { total += candidateVotes[i]; } return total; } void castVote(int voterId, int candidateIndex) { if (voterId < 1 || voterId > MAX_FINGERPRINTS) { return; } if (candidateIndex < 0 || candidateIndex >= NUM_CANDIDATES) { return; } candidateVotes[candidateIndex]++; hasVoted[voterId] = true; saveVoteForVoter(voterId); saveCandidateVotes(); String candName = String(CANDIDATE_NAMES[candidateIndex]); addLog("VOTE", voterId, "Voted for " + candName, candName); oledSuccessAnimation("Vote Cast", candName); smartDelay(1200); } void handleCandidateSelection() { server.handleClient(); if (millis() - voteWindowStart > VOTE_TIMEOUT_MS) { int voterId = pendingVoterId; addLog("VOTE TIMEOUT", voterId, "Candidate selection timed out"); isSelectingCandidate = false; pendingVoterId = -1; oledErrorAnimation("Time Expired", "Scan again"); smartDelay(1200); oledScanScreen(); return; } int candidateIndex = readCandidateButton(); if (candidateIndex < 0) { return; } int voterId = pendingVoterId; isSelectingCandidate = false; pendingVoterId = -1; castVote(voterId, candidateIndex); oledScanScreen(); } // ===================================================== // HELPERS // ===================================================== void waitForFingerRemove() { uint8_t p = finger.getImage(); while (p != FINGERPRINT_NOFINGER) { server.handleClient(); delay(100); p = finger.getImage(); } } uint16_t findNextFreeID(uint16_t startID) { if (startID < 1) { startID = 1; } for (uint16_t id = startID; id <= MAX_FINGERPRINTS; id++) { server.handleClient(); uint8_t p = finger.loadModel(id); if (p != FINGERPRINT_OK) { return id; } } return MAX_FINGERPRINTS; } void refreshTemplateCountSerialOnly() { uint8_t p = finger.getTemplateCount(); if (p == FINGERPRINT_OK) { cachedTemplateCount = finger.templateCount; Serial.print("Stored fingerprints: "); Serial.println(cachedTemplateCount); } else { Serial.println("Could not read template count."); } delay(20); } void refreshTemplateCountCache() { uint8_t p = finger.getTemplateCount(); if (p == FINGERPRINT_OK) { cachedTemplateCount = finger.templateCount; } delay(20); } void rebuildRegisteredCache() { String json = "{\"fingerprints\":["; bool first = true; for (uint16_t id = 1; id <= MAX_FINGERPRINTS; id++) { server.handleClient(); uint8_t p = finger.loadModel(id); if (p == FINGERPRINT_OK) { PersonProfile profile = loadProfile(id); if (!first) { json += ","; } json += "{"; json += "\"id\":" + String(id) + ","; json += "\"name\":\"" + jsonEscape(profile.name) + "\","; json += "\"collegeId\":\"" + jsonEscape(profile.collegeId) + "\","; json += "\"role\":\"" + jsonEscape(profile.role) + "\","; json += "\"department\":\"" + jsonEscape(profile.department) + "\","; json += "\"dob\":\"" + jsonEscape(profile.note) + "\""; json += "}"; first = false; } } json += "]}"; cachedRegisteredJson = json; } void setMatchingSecuritySerialOnly() { Serial.print("Setting security level to "); Serial.println(MATCH_SECURITY_LEVEL); uint8_t p = finger.setSecurityLevel(MATCH_SECURITY_LEVEL); if (p == FINGERPRINT_OK) { Serial.println("Security level updated."); } else { Serial.println("Could not update security level."); } delay(100); finger.getParameters(); Serial.print("Current security level: "); Serial.println(finger.security_level); } void printSensorParameters() { finger.getParameters(); Serial.println(); Serial.println("Sensor parameters:"); Serial.print("Status: 0x"); Serial.println(finger.status_reg, HEX); Serial.print("System ID: 0x"); Serial.println(finger.system_id, HEX); Serial.print("Capacity: "); Serial.println(finger.capacity); Serial.print("Security level: "); Serial.println(finger.security_level); Serial.print("Device address: "); Serial.println(finger.device_addr, HEX); Serial.print("Packet length: "); Serial.println(finger.packet_len); Serial.print("Baud rate: "); Serial.println(finger.baud_rate); Serial.println(); } |
dashboard.h code
Here is the header file for the project. Create another tab in the Arduino IDE editor window and paste the following code, which contains the complete live voting dashboard webpage.
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170 171 172 173 174 175 176 177 178 179 180 181 182 183 184 185 186 187 188 189 190 191 192 193 194 195 196 197 198 199 200 201 202 203 204 205 206 207 208 209 210 211 212 213 214 215 216 217 218 219 220 221 222 223 224 225 226 227 228 229 230 231 232 233 234 235 236 237 238 239 240 241 242 243 244 245 246 247 248 249 250 251 252 253 254 255 256 257 258 259 260 261 262 263 264 265 266 267 268 269 270 271 272 273 274 275 276 277 278 279 280 281 282 283 284 285 286 287 288 289 290 291 292 293 294 295 296 297 298 299 300 301 302 303 304 305 306 307 308 309 310 311 312 313 314 315 316 317 318 319 320 321 322 323 324 325 326 327 328 329 330 331 332 333 334 335 336 337 338 339 340 341 342 343 344 345 346 347 348 349 350 351 352 353 354 355 356 357 358 359 360 361 362 363 364 365 366 367 368 369 370 371 372 373 374 375 376 377 378 379 380 381 382 383 384 385 386 387 388 389 390 391 392 393 394 395 396 397 398 399 400 401 402 403 404 405 406 407 408 409 410 411 412 413 414 415 416 417 418 419 420 421 422 423 424 425 426 427 428 429 430 431 432 433 434 435 436 437 438 439 440 441 442 443 444 445 446 447 448 449 450 451 452 453 454 455 456 457 458 459 460 461 462 463 464 465 466 467 468 469 470 471 472 473 474 475 476 477 478 479 480 |
Testing & Demo of ESP32 Fingerprint Voting Machine
After completing the hardware connection and uploading the code, the ESP32 fingerprint voting machine is ready for testing.
When the device is powered on, the OLED display first shows the Wi-Fi connection status.
Once the ESP32 connects to the local Wi-Fi network, it displays the IP address on the OLED screen. This IP address can be opened in a web browser to access the live voting dashboard.
After Wi-Fi connection, the system checks the R503 fingerprint sensor. During this step, the OLED shows a checking message while the ESP32 communicates with the fingerprint module.
If the sensor is detected successfully, the OLED displays “Sensor Ready”, which means the fingerprint module is properly connected and ready for scanning.
Finally, the system enters scan mode. In this mode, the OLED displays “Place finger” and waits for a registered voter to scan before accepting a candidate button vote.
Accessing the Dashboard
After the ESP32 connects to the Wi-Fi network, it displays its local IP address on the OLED screen. In this demo, the IP address shown is 192.168.2.112. By entering this IP address in a web browser on a phone, laptop, or computer connected to the same Wi-Fi network, we can access the VoteTrack Pro live voting dashboard.
The dashboard page shows live election stats, vote distribution, Wi-Fi connection, latest update time, and live activity feed. From the left-side menu, we can open Dashboard, Enroll Voter, Live Results, and Voter Management.
The Enroll Voter page is used to add voter details such as name, ID number, date of birth, sex, and city, and then start fingerprint enrollment.
The Live Results page shows current vote counts, leading candidate, and vote history, while the Voter Management page displays registered voters and their voting status.
The dashboard also includes options to enable sound alerts, export vote data as a CSV file, and reset the election when required.
Registering Voters
To register a new voter, open the ESP32 web dashboard and go to the Enroll Voter section. Here, enter the voter details such as name, ID number, date of birth, sex, and city, then click the Start Registration button.
After starting the registration, the dashboard shows an “Enrollment Started” popup and the OLED display asks the user to place a finger on the R503 fingerprint sensor.
The sensor first captures the fingerprint image, then asks the user to remove the finger and place the same finger again for the second scan.
The OLED display shows the enrollment progress step by step, such as placing the finger, removing the finger, scanning again, and saving the fingerprint.
Once both scans are matched successfully, the fingerprint template is saved in the R503 sensor memory and the user details are stored in the ESP32.
The OLED display shows a success message, and the dashboard also displays a “Registration Successful” popup with the voter name, fingerprint ID, ID number, and other saved details.
If the same registered finger is scanned again during the registration process, the system detects it as a duplicate fingerprint.
After this, the registered voter can scan their finger and cast one vote during the election.
Casting a Vote
After voter registration, the system can be used to conduct the election.
When a registered voter places their finger on the R503 fingerprint sensor, the OLED display shows that the system is searching and verifying the fingerprint.
If the fingerprint matches a saved voter record and that voter has not voted yet, the ESP32 opens a voting window and asks the voter to press one of the four candidate buttons.
When the voter selects a candidate, the dashboard displays a vote success popup with the voter name, fingerprint ID, ID number, and selected candidate. The vote is saved immediately and shown in the live results panel.
If the same voter scans again after already voting, the system blocks duplicate voting and displays an “Already Voted” message on the OLED and dashboard.
If an unknown or unregistered finger is scanned, the OLED display shows a try again or search failed message.
This means the fingerprint is not found in the saved voter database. The dashboard also keeps updating the live activity feed, vote history, turnout, and registered voter records.
In the Live Results section, vote counts, percentages, leading candidate, and vote history are shown with voter name, ID number, fingerprint ID, candidate, and message.
The Voter Management section shows all registered voters along with their assigned fingerprint IDs, voting status, and delete option.
Apart from voter enrollment and vote casting, the dashboard also includes useful election management features. In the Voter Management section, all registered voters are listed with fingerprint ID, name, ID number, date of birth, sex, city, and voting status. If any voter record needs to be removed, the administrator can click the Delete button, and the ESP32 deletes that fingerprint ID from the R503 sensor memory as well as removes the saved voter details from the system.
The dashboard also provides an Export Votes CSV option and a Reset Election button. Exported vote data can be opened in Excel or Google Sheets for result analysis and record keeping.
